FM Radio Studio Packages
Description
Radio Studio Packages
All the Equipment you need to go On-Air and Producing : Complete Turnkey Solutions
A wide range of complete studio packages of different types and sizes, to suit every broadcaster for medium/small radios (local station, community radios, web radios)
Flexibility and robustness
ON AIR RADIO STUDIO PACKAGES
Radio Studio Package
On-Air Radio Studio Packages
On-Air Radio Studio Packages
On-Air Radio Studio Packages
Radio Studio Package
On-Air STUDIO BASIC Radio Studio Packages
PRODUCTION
Production STUDIO Start Radio Studio Packages
On-Air STUDIO Startpro Radio Studio Packages
On-Air STUDIO TOP Radio Studio Packages
Production STUDIO TOP Radio Studio Packages
RADIO STUDIO PACKAGE model BASIC
General composition
| Article | Description |
|---|---|
| Broadcast Desk | Broadcast desk mod. ETEC with anti-scratch surface desktop, 15U side-rack, cylindrical legs, incl. Rack 23U (8U + 15U) optional additional desk for guests with legs and place for hdp distributor |
| Work Station | WORKSTATION WS with Playout Basic SW, library & ingest, playlist,adv. management, runtime scheduler, audio editing. 4U Rackmount PC optional Digital Audio Card AES/EBU 4 XLR OUT 4 IN with XLR cable |
| Monitor | LED Monitor 23.6″ TN Full HD 1920x1080Display. |
| Chair | Chair for Broadcast desk, technicians and/or guests. |
| Telephone | Telephone set black with incoming call light indicator, Last number redial, Wall mountable, Message waiting indicator, Adjustable earpiece volume: 5 levels. |
| Telephone Hybrid | Telephone Hybrid, 2 lines with 2 GSM Module built in, High audio quality with balanced IN/OUT, ADJ SEND and RECIEVE level. |
| Headphones | Studio Stereo HEADPHONES Closed-back, or Semi Open, dynamic |
| Headphones Distributor | Headphones Distributor 4 or 6 indipendent OUT with level control. |
| Microphone | Cardioid Condenser Studio Microphone, Cardioid Condenser Element, Spider shockmount, Low Frequency Roll-Off, 20dB Pad. |
| Mic Arm | Mic Arm Table or Adjustable |
| Tuner | Professional 19” AM/FM RDS tuner controllable via RS232 or infrared.FM tuning range : 87.5 – 108 MHz,522 – 1611 kHz. Presets : 40, 230 VAC/50 Hz, 1U Rack, 230 VAC/50 Hz |
| Digital Tuner | Digital AM/FM Tuner with RDS, Auto Search & PLL Quartz Synthesizer Tuner, 20 station memory presets, Search by program type – Music, News, Economics, Weather, Sports, Educational, Drama, Arts & Culture and Science, IR remote control included |
| Mixer | Professional Modular Broadcast Mixer FRAME 6-8-12-16 channels Analogue or Digital, BLUETOOTH. Digital display with clock and time. |
| Audio Processor | Multi-Bands FM Audio Processor with Built-in RDS encoder & stereo Generator. Graphic Display, incremental encoder. 60dB 30- 15KHz Stereo separation, RDS 25 PS, 25 Radiotext (64 fonts), 24 AF lists. Inputs: SCA, analog on blanced XLR. |
| GSM Gateway | GSM gateway Dial 103, Dual-Band 900/1800 MHz, High audio quality. Incl. external antenna. |
| CD Player | “Cd Player WAW/MP3 with USB , jog dial for search/scan, Auto-cue. Fader start play. |
| Active Speakers | Pair of Active studio Monitor, LF Driver: 4,5″ (114 mm) Kevlar, HF Driver: 1″ (25 mm) silk dome, Frequency Response: 70 Hz – 20 kHz, Crossover Frequency: 2,8 kHz, LF Amplifier Power: 25W for speaker, Peak SPL (@ 1 meter): 100 dB, Input Impedance: 10 kOhms |
| Recorder | Solid State Recorder WAV & MP3 to Compact Flash, SD/SHC, and USB memory. Parallel and RS-232C serial control balanced & unbalanced I/O, and coaxial digital I/O. It supports the RC-20 direct play remote for up to 20 tracks of flash start. |
| UPS | UPS 1,5KVA (1500 VA) 10′ Autonomy, 3x12V 9Ah. ON-Line Technology Dual Conversion, Wide input range, programmable output plugs, LCD Display, Frequency Converter 50/60 Hz function, EPO (Emergency Power Off) Function, Automatic/manual By-pass. 2U rack. |
| Switch Hub | 8-Port Desktop Gigabit Ethernet Media Switch for multiple media devices connection to networks at blazing-fast Gigabit simultaneously. |
| On-Air Light | Professional ON AIR Light for Broadcast Facilities. Polycarbonate Graphic Panel, Laser cut. RJ45 connection, operating and Output Voltage 12 Vdc. Current 330 mA. Input Voltage 100-240Vac. Product Dim.: W 38,3cm D 4,2 cm H 13,5 cm 1 Kg. |
| Prewiring | Prewiring ON AIR STUDIO and PRODUCTION STUDIO including: cables, connectors, interconnection cables (100 Mt.Balanced audio cable, 100 MPX cable, 100 Mt. Lan Cable) and factory test. |
